Product Details:
|
| Size: | 1"-80" | Standard: | ANSI EN1092 DIN |
|---|---|---|---|
| DN: | DN15-DN2000 | Type: | Type01 Plate Flange, Type02 Loose Flange, Type05 Blind Flange, Type11 Welding Necking Type12 Slip On Flange, Type 13 Threaded Flange |
| Use: | Flange Connecting Pipe To Pipe, Flange Connecting Valve To Pipe, Flange Connecting Pump To Motor | Packing: | Wooden Case,wooden Pallet |
| Pressure: | PN6, PN10, PN16, PN25, PN40, PN64, PN100 | Material: | A105,20#、Q235、16Mn、 ASTM A350 LF1,LF2 CL1/CL2,LF3 CL1/CL2、ASTM A694 F42,F46,F48,F50,F52,F56,F60,F65,F70 |
| High Light: | PN16 DN15 galvanized steel pipe flange,C207 metal pipe flange,DN15 galvanized steel pipe flange |
||
PN16 PN25 PN40 PN64 PN100 Pressure Pipe Fitting Carbon Steel Flanges
ANSI B16.5, ASME B16.5/B16.47 FLANGESize range: 1/2" to 80" DN15 to DN2000 Design: welding neck, slip on, blind, socket welding, threaded, lap-joint Pressure: 150#, 300#, 600#,900#,1500#, 2500# Wall thickness for welding neck flange: STD, SCH40, SCH80, SCH160. SCHXXS
Material: Carbon steel A105, Stainless steel 304/304L, 316/316L Coating: black paint, yellow transparent paint, cold and hot dip galvanize EN1092-1 FLANGE Size range: DN15 to DN2000 Design: type01 plate flange, type02 loose flange, type05 blind flange, type11 welding necking type12 slip on flange, type 13 threaded flange Pressure: PN6, PN10, PN16, PN25, PN40, PN64, PN100 Material: Carbon steel C22.8, S235, S235JR, P235GH, P245GH,P250GH,P280GH,P265GH.
Stainless steel: 304/304L, 316/316L Coating: black paint, yellow transparent paint, cold and hot dip galvanize DIN FLANGE Size range: DN15 to DN2000 Design: slip on flange DIN2573,2576,2502,2503, 2543,2545 welding neck falnge DIN2631, 2632,2633,2634,2635 blind flange DIN 2527 PN6, PN10, PN16, PN25, PN40 threaded falnge DIN2565,2566,2567,2567 loose flange DIN 2641,2642,2656,2673
| Standard | ANSI B16.5,ASME B16.47, MSS-SP44, API, and AWWA-C207. |
| Class | 150#, 175#, 250#, 300#, 350#, 400#, 600#, 900#, 1500# |
| Type | welding neck flange |
| Use | Industry Pipeline, Water Projects,connecting pipe to pipe, valve to pipe, pump to motor |
| Origin | China Factory |
